01 What the Jay Flight line is
Jay Flight is Jayco's mass-market travel trailer and the volume seller in its towable range. For the 2027 model year Jayco markets it as Jay Flight — the nameplate's 25th anniversary — alongside a separate, lighter Jay Flight SLX, which Jayco's own site navigation lists as its own travel-trailer entry.
The 2027 roster runs thirty floorplans. Nineteen carry an 8-cubic-foot refrigerator and eleven an 11-cubic-foot one, and the same nineteen/eleven boundary appears in the aggregator's axle field — but those are two columns of one spec block, not two independent witnesses, and the axle column does not survive checking. Jayco's factory pages for all thirty floorplans were fetched on 29 July 2026 and settle it: the line runs seven single-axle plans and twenty-three double, not nineteen and eleven. Twelve floorplans the aggregator calls single-axle are double-axle units at the factory. Axle counts are now published on all thirty, sourced from Jayco. Dry weights run 3,190 to 8,655 pounds and GVWRs 4,500 to 10,600, so the light end sits within reach of a properly equipped mid-size truck or large SUV while the 325BHT and 380DQS want a capable half-ton-plus. Cargo capacity — the number that actually decides what you can load — runs 1,030 to 2,125 pounds and does not rise smoothly with size.
Eighteen plans are eastern builds and twelve are western, marked with a trailing W. They are not cosmetic variants: a western 200MKSW lists at $41,243 against $32,993 for the eastern 200MKS, and the Baja off-grid package is an option on western-built units only. Where both exist, they are listed as separate rows below because they are separately specified trailers.
A 25th Anniversary Package is mandatory on both single- and double-axle builds for 2027 and is not available on the Sport Edition trim, which carries its own mandatory Customer Value Package. Fifty-amp service is standard on the 325BHT, 334RTS and 380DQS; a residential refrigerator replaces the 12-volt unit on the 380DQS. The fireplace is not available on the 225MLS and the outside griddle is not available on the 265TH.
02 All 54 floorplans — verified weights
Every 2027 Jay Flight floorplan, sorted by dry weight, plus the three profiled plans from Jay Flight Bungalow — the destination-trailer roster Jayco builds under the same name, named in its own rows. Each row was fetched individually from its own spec-grade record and identity-checked against that record's title before the figures were taken. Dry weight plus cargo capacity equals GVWR exactly on all 54 plans in this table — no plan on this page carries a weight that fails to reconcile.
| Floorplan | Dry wt | GVWR | Cargo | Length | Sleeps | Slides | Layout | MSRP |
|---|---|---|---|---|---|---|---|---|
| 401FLTS | 10,355 | 12,000 | 1,645 | 40' 4" | 4 | —‡ | Jay Flight Bungalow · tongue 1,515 lb · 8' 0" interior | —‡ |
| 401LOFT | 11,575 | 13,400 | 1,825 | 42' 0" | 8 | —‡ | Jay Flight Bungalow · tongue 1,465 lb · 8' 10" interior | —‡ |
| 404LOFT | 11,750 | 13,600 | 1,850 | 42' 0" | 8 | —‡ | Jay Flight Bungalow · tongue 1,610 lb · 8' 11" interior | —‡ |
| 130BHW | 2,450 | 3,500 | 1,050 | 16' 1" | 4 | —‡ | Tongue 260 lb · 6' 6" interior | —‡ |
| 130BH | 2,460 | 3,500 | 1,040 | 16' 1" | 4 | —‡ | Tongue 240 lb · 6' 6" interior | —‡ |
| 130RDW | 2,530 | 3,500 | 970 | 16' 1" | 4 | —‡ | Tongue 230 lb · 6' 6" interior | —‡ |
| 140TBW | 2,565 | 3,500 | 935 | 17' 6" | 2 | —‡ | Tongue 310 lb · 6' 6" interior | —‡ |
| 170BHW | 2,880 | 3,750 | 870 | 21' 3" | 4 | —‡ | Tongue 330 lb · 6' 6" interior | —‡ |
| 170FQW | 2,940 | 3,850 | 910 | 21' 5" | 4 | —‡ | Tongue 280 lb · 6' 6" interior | —‡ |
| 170FQ | 3,060 | 3,850 | 790 | 21' 5" | 4 | —‡ | Tongue 275 lb · 6' 6" interior | —‡ |
| 172DBW | 3,180 | 3,995 | 815 | 22' 5" | 6 | —‡ | Tongue 415 lb · 6' 6" interior | —‡ |
| 175FQ | 3,260 | 4,500 | 1,240 | 22' 1" | 4 | —‡ | Tongue 305 lb · 6' 6" interior | —‡ |
| 172DB | 3,270 | 3,995 | 725 | 22' 5" | 6 | —‡ | Tongue 405 lb · 6' 6" interior | —‡ |
| 178DBSW | 3,615 | 4,800 | 1,185 | 23' 7" | 8 | —‡ | Tongue 505 lb · 6' 6" interior | —‡ |
| 178DBS | 3,730 | 4,800 | 1,070 | 23' 7" | 8 | —‡ | Tongue 515 lb · 6' 6" interior | —‡ |
| 250BHW | 4,100 | 6,000 | 1,900 | 27' 7" | 10 | —‡ | Tongue 480 lb · 6' 6" interior | —‡ |
| 211MBW | 4,265 | 6,300 | 2,035 | 24' 6" | 8 | —‡ | Tongue 540 lb · 6' 9" interior | —‡ |
| 265TH | 5,260 | 8,500 | 3,240 | 30' 4" | 4 | —‡ | Tongue 885 lb · 6' 9" interior | —‡ |
| 225MLS | 5,280 | 6,900 | 1,620 | 27' 1" | 4 | —‡ | Tongue 555 lb · 6' 9" interior | —‡ |
| 270BHSW | 5,380 | 7,000 | 1,620 | 31' 10" | 10 | —‡ | Tongue 760 lb · 6' 6" interior | —‡ |
| 270BHS | 5,590 | 7,000 | 1,410 | 31' 10" | 10 | —‡ | Tongue 725 lb · 6' 6" interior | —‡ |
| 263BHS | 6,335 | 8,200 | 1,865 | 32' 6" | 10 | —‡ | Tongue 785 lb · 6' 9" interior | —‡ |
| 280BHS | 6,515 | 8,500 | 1,985 | 34' 1" | 10 | —‡ | Tongue 775 lb · 6' 9" interior | —‡ |
| 335BHS | 6,925 | 9,000 | 2,075 | 37' 7" | 10 | —‡ | Tongue 975 lb · 6' 9" interior | —‡ |
| 175FQW | 3,190 | 4,500 | 1,310 | 22' 1" | 6 | 0† | Front-queen couples (western) | $24,518 |
| 175BHW | 3,260 | 4,600 | 1,340 | 22' 3" | 6 | 0† | Bunkhouse (western) | $24,518 |
| 175BH | 3,285 | 4,600 | 1,315 | 22' 3" | 6 | 0† | Bunkhouse | $22,643 |
| 180LK | 3,555 | 4,800 | 1,245 | 22' 9" | 4 | 1 | Loft-kitchen couples | $26,168 |
| 180LKW | 3,645 | 4,950 | 1,305 | 22' 9" | 4 | 1 | Loft-kitchen couples (western) | $28,043 |
| 197MBW | 3,900 | 5,150 | 1,250 | 23' 7" | 8 | 1 | Murphy-bed couples (western) | $29,318 |
| 197MB | 3,965 | 4,995 | 1,030 | 23' 7" | 8 | 1 | Murphy-bed couples | $27,443 |
| 210QB | 4,275 | 6,000 | 1,725 | 25' 8" | 6 | 0† | Rear-queen couples | $29,406 |
| 210QBW | 4,420 | 6,200 | 1,780 | 25' 8" | 6 | 0† | Rear-queen couples (western) | $36,531 |
| 260BH | 4,750 | 6,500 | 1,750 | 29' 5" | 8 | 0† | Bunkhouse | $29,406 |
| 200MKSW | 4,840 | 6,500 | 1,660 | 24' 7" | 2 | 1 | Mid-kitchen couples (western) | $41,243 |
| 260BHW | 4,905 | 6,800 | 1,895 | 29' 5" | 10 | 0† | Bunkhouse (western) | $31,281 |
| 200MKS | 4,965 | 6,500 | 1,535 | 24' 7" | 2 | 1 | Mid-kitchen couples | $32,993 |
| 225MLSW | 5,220 | 6,995 | 1,775 | 27' 1" | 6 | 1 | Mid-living slide (western) | $44,625 |
| 245BHSW | 5,460 | 7,000 | 1,540 | 28' 7" | 6 | 1 | Bunkhouse + slide (western) | $37,043 |
| 245BHS | 5,555 | 7,200 | 1,645 | 28' 7" | 8 | 1 | Bunkhouse + slide | $34,043 |
| 261BHSW | 5,765 | 7,600 | 1,835 | 30' 3" | 10 | 1 | Bunkhouse + slide (western) | $38,406 |
| 265MWS | 5,770 | 7,700 | 1,930 | 29' 10" | 6 | 1 | Mid-wardrobe slide | $41,393 |
| 261BHS | 5,975 | 7,600 | 1,625 | 30' 4" | 10 | 1 | Bunkhouse + slide, sleeps 10 | $40,656 |
| 262RLS | 6,205 | 7,900 | 1,695 | 31' 1" | 6 | 1 | Rear-living couples | $41,031 |
| 263BHSW | 6,250 | 8,200 | 1,950 | 32' 7" | 10 | 1 | Bunkhouse + slide (western) | $39,893 |
| 262RLSW | 6,290 | 8,100 | 1,810 | 31' 1" | 6 | 1 | Rear-living couples (western) | $38,781 |
| 295TBS | 7,180 | 9,300 | 2,120 | 36' 10" | 9 | 1 | Two-bedroom slide | $47,018 |
| 330TBS | 7,280 | 9,300 | 2,020 | 37' 7" | 10 | 1 | Two-bedroom slide | $41,393 |
| 290RLS | 7,575 | 9,600 | 2,025 | 34' 9" | 6 | 2 | Rear-living, twin slide | $52,943 |
| 321BDS | 7,810 | 9,800 | 1,990 | 36' 4" | 11 | 2 | Bunk + dinette, twin slide | $49,493 |
| 333BTS | 8,375 | 10,500 | 2,125 | 37' 10" | 11 | 1 | Bunk family, sleeps 11 | $51,743 |
| 380DQS | 8,430 | 10,500 | 2,070 | 40' 4" | 8 | 2 | Double-queen, twin slide | $49,800 |
| 325BHT | 8,475 | 10,600 | 2,125 | 38' 4" | 11 | 3 | Triple-slide bunkhouse | $54,961 |
| 334RTS | 8,655 | 10,600 | 1,945 | 37' 10" | 8 | 3 | Rear twin, triple slide | $52,875 |
Weights, lengths, sleeping capacity, slide count and MSRP are from RVUSA structured specification records, one fetch per floorplan, 29 Jul 2026. † RVUSA omits the slide field entirely on zero-slide plans; the 0 shown for those seven is the figure published on RVUSA's own 2027 Jay Flight model index, which agrees with the individual plan record on all twenty-three plans that do carry the field. Cargo capacity is RVUSA's published payload figure. Tongue weight is not published here — the source carries hitch type (bumper pull, on all thirty) and no tongue weight, and nothing on this site is estimated to fill a column. Options change weights; confirm against the unit's own weight sticker before purchase. ‡ The 21 plans added 2 Aug 2026 are verified against Jayco’s own factory floorplan pages, not RVUSA. That source publishes no slide count and no MSRP, so those two cells are left empty for those rows rather than filled from an RVUSA sibling — an em dash here means the manufacturer does not publish the figure, never that it is zero. ‡ The 3 Jay Flight Bungalow rows added 2 Aug 2026 are a separate factory roster: destination trailers built for seasonal placement, not touring, and over forty feet long. They are verified against Jayco’s own MY2027 factory floorplan pages, which publish no slide count and no MSRP, so those cells are empty rather than filled from another source.
03 Where the sources disagree
Five disagreements were open on this line. Four remain printed rather than reconciled, because reconciling them would mean picking a winner without evidence. The fifth — the axle row, the one that changed what this site publishes — is now settled by Jayco's own per-floorplan pages, and is kept here so that anyone cross-checking against the aggregator can see why the two differ.
| Quantity | Jayco | RVUSA | Status |
|---|---|---|---|
| Axle count | Jayco factory per-plan pages: 7 single-axle, 23 double-axle | 1 axle on all 19 plans up to 265MWS — including 12 the factory builds as double-axle | Resolved 29 Jul 2026 in favour of the factory; all 30 counts now published |
| Length range | 16' 1"–40' 4" (spec block) 21' 5"–38' 4" (prose) | 22' 1"–40' 4" | Maxima tie exactly; minima do not |
| Dry weight floor | 2,450 lb | 3,190 lb | Ceiling ties exactly at 8,655 lb |
| Starting MSRP | $17,468 | $22,643 | Unresolved |
| Roster size | 5 plans named in equipment copy | absent from the 30-plan roster | Unconfirmed for MY2027 |
On the ranges. Jayco publishes two different length ranges on one page — a structured spec block and a prose paragraph that disagree with each other. RVUSA's roster corroborates the spec block's maximum exactly (40' 4", the 380DQS) and contradicts the prose maximum. Its minimum matches neither. The two publishers may simply be measuring different things: exterior length against box length is a measurement difference, not an error by either. The same pattern appears in the weights, where the ceiling ties to the pound and the floor does not — consistent with Jayco's floor figure describing a plan that is not on RVUSA's 2027 roster.
On the price. Jayco advertises the line as starting at $17,468. The cheapest plan on the 2027 roster, the 175BH, lists at $22,643. The factory figure may predate the mandatory Customer Value and 25th Anniversary packages — but that is a guess, so both figures are published and attributed instead.
On the five missing plans. The 225MLS (bare — only the western 225MLSW is on the roster), 265BHS, 265TH, 270BHS and 382FRK are all named in Jayco's own 2027 standard- and optional-equipment copy, and none appears on RVUSA's 2027 roster. Either the roster is incomplete or the equipment copy carries model numbers forward from a previous year — the same suspicion the prose length range raises. Neither reading is evidenced, so all five are treated as unconfirmed for 2027 and are not listed above. Checked 29 Jul 2026 against MY2027.
04 Where it sits in Jayco's range
Jay Flight is the value flagship. Jayco's 2027 travel-trailer navigation lists it and Jay Flight SLX separately, and the step-up lines sit above both.
| Line | Tier | Status | Distinguishing position |
|---|---|---|---|
| Jay Flight | Value flagship | Current · MY2027 | 30 plans, 22–40 ft; 25th anniversary model year |
| Jay Flight SLX | Value lightweight | Current | The lighter half of the nameplate; sold as the whole line for MY2026 |
| Jay Feather | Mid / step-up | Current | Norco® Z-frame, 11 cu ft fridge, residential touches |
| Eagle HT (TT) | Premium | Current | Climate Shield, 4-Star Handling, larger and heavier |
Reading the SLX split. For the 2026 model year Jayco sold the value range as a single Jay Flight SLX line, and this site's six 2026 SLX floorplan pages are records of that year — they remain correct and are not superseded by this page. For 2027 the flagship nameplate returned as Jay Flight and SLX continues alongside it: 2027 SLX units are in dealer inventory under 295TBS, 261BHS, 197MB and 170BH. RVUSA lists Jay Flight model years 2027, 2025, 2024 and 2023 with no 2026 entry, which is consistent with 2026 having been sold under the SLX name. Checked 29 Jul 2026 against MY2027.
05 Line & model-year notes
Eastern and western builds are different trailers
Twelve of the thirty plans carry a trailing W and are built at Jayco's western plant. Where an eastern and a western version of the same floorplan both exist, they can differ in weight and differ substantially in price — the 200MKS and 200MKSW are $8,250 apart. The Baja off-grid package is optional on western-built units only. Treat them as separate trailers when shopping, not as regional badging.
Cargo capacity does not scale with length
The heaviest plan is not the one with the most payload. Cargo capacity across the roster runs 1,030 to 2,125 pounds and moves independently of size, so a longer trailer can leave you less room to load. It is the number to check first if you carry water, gear or a generator, and it is listed for every plan in the table above.
The fridge does not tell you the axle count
Nineteen of the thirty 2027 Jay Flight plans carry an 8-cubic-foot refrigerator and eleven an 11-cubic-foot one, without exception across all thirty records. That split is directly observed and is not in dispute. What does not hold is the inference drawn from it. Against Jayco's own factory axle counts, an 11-cubic-foot refrigerator does imply a double-axle unit — all eleven are double. An 8-cubic-foot refrigerator implies nothing: seven of those nineteen are single-axle and twelve are double. The apparent nineteen/eleven axle boundary was the aggregator's axle field agreeing with the aggregator's refrigerator field, one spec block agreeing with itself. A residential refrigerator replaces the 12-volt unit on the 380DQS.
Packages are mandatory, and they move the price
For 2027 the 25th Anniversary Package is required on both single- and double-axle builds, and the Sport Edition trim carries its own mandatory Customer Value Package instead (the anniversary package is not available on it). Sport Edition also swaps the 60,000-BTU tankless water heater for a 42,000-BTU unit. Mandatory packages are the most likely explanation for the gap between Jayco's advertised starting price and the roster's cheapest plan, but that link is not evidenced — see section 03.
06 What the 2027 roster shows
07 Recalls
NHTSA lists 25 recall campaigns affecting this line. The earliest was reported 19 Apr 2006 and the most recent 14 Oct 2022.
| Reported | Campaign | Component | What can go wrong |
|---|---|---|---|
| 14 Oct 2022 | 22V773000 | Equipment | An inverted cooktop flame increases the risk of injury or fire. |
| 4 Aug 2022 | 22V571000 | Structure | An awning that drops or extends beyond normal operation can increase the risk of injury. |
| 2 Sep 2021 | 21V685000 | Equipment | Increased propane pressure can enlarge the flames in gas appliances, increasing the risk of a fire. |
| 4 Jun 2021 | 21V425000 | Equipment | Increased propane pressure can enlarge the flames in gas appliances, increasing the risk of a fire. |
| 17 Mar 2021 | 21V184000 | Equipment | A gas leak can increase the risk of a fire. |
| 9 Jun 2020 | 20V336000 | Visibility | If the window glass detaches while the vehicle is moving it could become a projectile, increasing the risk of injury or a crash. |
| 30 Apr 2019 | 19V335000 | Equipment | A detached water tank would be a road hazard, increasing the risk of crash. |
| 2 Oct 2018 | 18V686000 | Electrical system | If the rear turn signals and brake lights do not operate as intended, other drivers will not be properly notified of stopping or turning, increasing the risk of a… |
| 12 Sep 2018 | 18V618000 | Suspension | The missing bearing race may cause premature hub bearing failure, possibly resulting in a separation of the hub from the axle, thereby increasing the risk of a… |
| 21 Nov 2017 | 17V746000 | Equipment | In the event of a fire, if the fire extinguisher does not function properly, it can increase the risk of injury. |
| 1 May 2017 | 17V290000 | Interior lighting | The excessive heat from the LED ceiling lights may increase the risk of a fire. |
| 27 Jul 2016 | 16V560000 | Electrical system | A loss of trailer brakes may lengthen the distance needed to stop the vehicle and cause a loss of vehicle control, increasing the risk of a crash. |
| 20 May 2016 | 16V305000 | Equipment | Incorrect weight ratings on the tire label could cause the operator to overload the vehicle and lead to premature tire wear, increasing the risk of a crash. |
| 4 Nov 2014 | 14V697000 | Equipment | A vehicle operator could inadvertently overload the trailer due to the incorrect information on the label and induce premature tire wear or a tire failure… |
| 23 Sep 2014 | 14V585000 | Equipment | In the event of a situation where the propane gas continues to flow, if the gas range cannot vent, an ignition source may ignite the propane gas, resulting in a… |
| 12 Sep 2014 | 14V561000 | Equipment | If the ladder does not have the support of the backer, when the ladder is used, the screws can pull out of the trailer wall and the ladder may give, increasing the… |
| 18 Oct 2013 | 13V514000 | Electrical system | A poor wiring connection could increase the wiring's resistance, causing excessive heat, resulting in an increased risk of fire. |
| 30 Apr 2013 | 13V168000 | Equipment | If motor damage occurs, it is possible that the awning can unfurl unexpectedly, either while the motorhome is at rest or while in transit, increasing the risk of… |
| 1 Mar 2013 | 13V070000 | Electrical system | An electrical short may lead to a vehicle fire. |
| 27 Apr 2012 | 12V183000 | Equipment | Relying ON the A misprinted label could lead TO improper vehicle loading specifications OR tire inflation which could result IN A tire failure, increasing the risk… |
| 11 Nov 2011 | 11V554000 | Equipment | This could result IN A fire, injury OR death. |
| 21 Apr 2011 | 11V251000 | Equipment | IF the jack comes loose while the vehicle IS IN motion A crash, injury OR death may result. |
| 21 Oct 2010 | 10V500000 | Equipment | A propane leak IN the presence OF AN ignition source could result IN A fire and/or explosion causing property damage and/or personal injury. |
| 20 Mar 2007 | 07V118000 | Structure | A person could BE injured should the step give way while being used TO enter OR exit the trailer. |
| 19 Apr 2006 | 06V123000 | Equipment | Misprinted labels could lead TO failure TO follow proper vehicle loading specifications OR tire inflation recommendation which could result IN tire failure… |
Coverage is not complete, and this matters. These campaigns come from two passes over NHTSA’s public record: a query-by-query harvest of the recall API (1,556 queries, of which 0 failed and 242 returned an explicit zero), and a sweep of NHTSA’s complete recall flat file (325,650 rows), which added 46 campaigns the API harvest had missed. It missed them because the roster it worked from was built by a catalog endpoint that refuses most requests, so entire manufacturer names were never asked about — NHTSA files several Forest River sub-brands as makes of their own. Two limits remain: NHTSA sometimes files a roster under a parent name, and some matches below rest on the wording of the recall rather than its model field. Campaigns affecting only pre-2005 units fall outside this catalog’s range and are not listed. This page is a starting point, not a clearance. Check a specific VIN at NHTSA before you buy, and again before you tow.
08 Owner-reported problems
Owners have filed 80 complaints with NHTSA about this line. The earliest was filed 17 Sep 2004 and the most recent 2 Aug 2025. The breakdown below is what those owners actually reported, grouped by the component NHTSA assigned.
Safety outcomes in this set: 5 reports describing a fire. These are the owner’s own account of what happened and have not been verified by NHTSA.
What gets reported
| Component group | Reports | Share |
|---|---|---|
| Equipment | 34 | 42% |
| Unknown or other | 10 | 12% |
| Structure | 9 | 11% |
| Electrical system | 8 | 10% |
| Latches/locks/linkages | 4 | 5% |
| Suspension | 4 | 5% |
| Exterior lighting | 3 | 4% |
| Tires | 2 | 2% |
| Wheels | 2 | 2% |
| Fuel/propulsion system | 1 | 1% |
| Interior lighting | 1 | 1% |
| Service brakes | 1 | 1% |
| Service brakes, electric | 1 | 1% |
Most recent reports
The most recent 10 owner reports filed on this line, newest first. Wording is NHTSA’s summary of what the owner described.
| Filed | Component | Miles | What the owner reported |
|---|---|---|---|
| 2 Aug 2025 | Suspension › Rear › Springs › Leaf spring… | — | Bought the trailer brand new. One of the leaf springs completely snapped and broke while driving on a smooth road. Trailer was not overloaded. Leaf springs were replaced twice by warranty with the same parts and the springs were flat and W shaped each time. The are supposed to be U shaped. The part… |
| 23 Jun 2025 | Equipment › Recreational vehicle/trailer | — | The entry door on my Jayco 264BH has become extremely difficult to open and close because the bottom of the door is rubbing against or making contact with the frame. This makes it nearly impossible for children to enter or exit the RV safely. In addition, closing the door from inside the RV is very… |
| 23 Apr 2025 | Equipment | — | The contact owns a 2021 Jayco Jay Flight. The contact stated that while utilizing the RV for recreational purposes, the contact became aware that the propane stove, furnace, and water heater were no longer functioning. No warning lights were illuminated. The RV was taken to an independent mechanic… |
| 5 Aug 2024 | Latches/locks/linkages › Doors › Latch | — | The contact owns a 2023 Jayco Jay Flight Trailer. The contact stated that an MKing keyless entry door lock was installed on the trailer. The contact stated that while driving at an undisclosed speed, the RV door opened independently. The RV was not diagnosed or repaired by an independent mechanic… |
| 18 Feb 2024 | Unknown or other | — | Our RV experienced frame failure twice. It was repaired by the rv facility the first time as it was under warranty. 2nd time it was not. This is a widespread and ongoing issue on Lippert frames and needs to be on a recall. The danger of a 45ft 5th wheel frame breaking on a major freeway could be… |
| 29 Sep 2023 | Structure › Body | — | Winntec LPG Regulator Modell 6020 PI.0-15.6 q6.R280 Mh26696 This regulator failed and caused our fridge to overheat and catch fire causing damage to the roof and fridge area.I feel someone should be responsible for the damage caused by this regulator.Thank you |
| 5 Jul 2023 | Unknown or other | — | NHTSA Campaign Number: 22V571000 Vehicle was sold to me new with recall remedy NOT complete |
| 5 Jul 2023 | Structure | 20 | The contact owns a 2022 Jayco Jayflight RV. The contact stated while opening the electric retractable awning, the fabric separated from the rails on the camper. The dealer was contacted and stated that the failure experienced was not related to NHTSA Campaign Number: 22V571000 (Structure). The… |
| 2 Jul 2023 | Wheels | — | We recently purchased this camper and in preparation I crawled under it and looked around and what I saw made me cringe. The welding on the frame was the worst welding I've seen in years on a product for sale the main beams that tie the camper front to back were only welded on one side of the beam… |
| 11 Jun 2023 | Equipment › Recreational vehicle/trailer | — | 174BH-rear emergency latch is not secure when opened it can easily become ajar and may strike child in the eye causing damage. Small bumps in to the handle cause the window to shut and the handle to move back into the sleeping quarters. Further in the event a child needed to escape the window one… |
How this count is drawn. A report is counted here only when NHTSA’s own model field names this line. What the owner typed in the description is never used to attribute a report: our line names are ordinary English words, and an owner writing “imagine my surprise when the axle went” or naming the state of Montana is not reporting a Grand Design Imagine or a Keystone Montana. Held out of it: Jay Flight Bungalow (destination/park trailer, a distinct Jayco series), Jay Flight G2 (generation badge, unverified against a factory source; 2 rows), Jay Flight Swift (the series that became Jay Flight SLX, which is its own line) and Jay Flight Swift SLX (Jay Flight SLX lineage, not the full-size Jay Flight). An independent sweep of NHTSA’s complaint API found 8 reports filed under Jay Flight Bungalow, Jay Flight G2, Jay Flight Swift and Jay Flight Swift SLX; none of them is counted above.
Read these as reports, not as findings. Complaints are submitted by owners and NHTSA does not verify them; no complaint here has been confirmed as a defect, and none of them is a recall. The sample is also self-selected — only owners motivated to file appear in it — so a high count tracks how many units a line sold at least as much as how well it was built. Use the pattern, not the total: a component that keeps recurring is worth inspecting on any used unit. File or search complaints at NHTSA.
